제품 상세 정보:
|
| 실린더 직경: | 430mm | 기계 테스트: | 제공 |
|---|---|---|---|
| 애플리케이션: | 물결모양 통 박스 | 두께: | 2-10mm |
| 재료: | 골판지 | 제품명: | 물결모양 카톤 박스 기계 |
| 제어 시스템: | PLC | 먹이는 방법: | 자동 피드 |
| 강조하다: | corrugated automatic feeding machinery,large scale packaging machinery,corrugated carton box machine |
||
| Model | QD-ZYKM1224 |
| Max Machine Speed (Roller Feeder Pcs/min) | 220 |
| Common Spending Max | 1200*2450 |
| Min. Paper Feeding Size (mm) | 320×600 |
| Max. Printing Area (mm) | 1200x2400 |
| Printing Plate Thickness (mm) | 7.2 |
| Machine Wall Thickness | 65mm |
| Printing Accuracy (mm) | ≤±0.4 |
| Print Roller Diameter (mm) | 408 |
| Slot Knives Width (mm) | 7.5mm |
| Die Cutting Accuracy (mm) | ±1.0 |
| No. | Component | Specification |
|---|---|---|
| 1 | Machine Wall | Thickness 60mm |
| 2 | Touch Screen | PLC, touch screen from France Schneider |
| 3 | Converter | France Schneider |
| 4 | Bearings | HRB |
| 5 | Gears | GRIDING TYPE |
| 6 | Electrical Elements | SCHNEIDER France |
| 7 | Frequency Converter | TaiWan Delta |
| 8 | Doctor Blade | Guangdong |
| 9 | Ceramic Anilox Cylinder | Shangyun (Grade A Quality) |
| 10 | Anilox Roll | JingHui (Grade A quality) |
